Crumpled Graphene Sheets (R1H)
Crumpled Graphene Sheets (R1H), 20g
Product Detail
1. Production Method
Our proprietary sequential hybrid plasma, only using natural gas as feedstock to produce unique and consistent crumpled graphene sheets. Produced in collaboration with Rimere.
2. Specifications
|
Product Name |
Crumpled Graphene Sheets (R1H) |
|
Morphology: |
Thin-layer crumpled graphene flakes |
|
Purity: |
>99% Carbon, <1% Oxygen, 0% Other |
|
Surface Area: |
210 ± 5 m2/g |
|
Single Particle Size (Average): |
200 nm |
|
Particle Shape: |
Crumpled Sheet |
|
Bulk Form: |
Black Powder |
|
Layers: |
1-12 Layers |
|
Conductivity: |
≤ 4,000 S/m |
|
Zeta Potential: |
-52 mV (Huckel/Henry) |
|
Sp2 Bonds: |
Detected |
|
2D/G Ratio: |
1.28 |
|
D/G Ratio: |
0.36 |
|
Tapped Density: |
0.0233 g/ml |
TEM Image of Crumpled Graphene Sheets (R1H)
SEM Image of Crumpled Graphene Sheets (R1H)
Raman of Crumpled Graphene Sheets (R1H)
4. Applications
- Battery electrodes, conductive additive
- Supercapacitors - electrodes, conductive additive
- Catalyst
- Conductive polymers
- Metamaterials
- Transparent conductive coatings
- EM Shielding
