Y-type Series Zeolites

As low as $186.00 $0.00
In stock
SKU# 123

Product Detail

Y-type series zeolites are characterized by large, essentially spherical, internal cavities often called supercages that are linked through pore openings less than 1 nm and are externally defined by rings of oxygen atoms. ACS Material’s Y-type series zeolites have a SiO2/Al2O3 molar ratio of 5–6, are calcined and ready to use directly, and include Y-RE2, Y-RE2-Pe, Y-RE16, Y-RE16-Pe, Na-Y and Na-Y-Pe.

These zeolites are effective as a cracking catalyst in converting petroleum crude to diesel, gas, and other products. They are also used in detergent manufacturing, odor control, gas adsorption, wastewater filtration, and soil remediation. Y-type series zeolites act as a flocculating agent and industrial filler, and they’re an important ingredient in animal feeds, desiccants, lightweight concrete, and ceramics.

Key specifications at a glance
GradesY-RE2, Y-RE2-Pe, Y-RE16, Na-Y
SiO2/Al2O3 molar ratio5–6
FormsPowder or pellet (2–3 mm)
BET surface area≥578 to ≥650 m²/g
D50<6 µm
SuppliedCalcined, ready to use

Product information

ParameterValue
Product nameY-type Series Zeolites
CAS No.1318-02-1
SuppliedCalcined and ready to use directly

Characterizations

CharacterizationsY-RE2*Y-RE2-Pe*Y-RE16*Y-RE16-Pe (Discontinued)Na-YNa-Y-Pe (Discontinued)
FormPowderPelletPowderPelletPowderPellet
SiO2/Al2O3 molar ratio5–65–65–65–65–65–6
DiameterN/A2–3 mmN/A2–3 mmN/A2–3 mm
LengthN/A~20 mmN/A~20 mmN/A~20 mm
Unit cell size<2.453 nm<2.453 nm<2.470 nm<2.470 nm2.465–2.472 nm2.465–2.472 nm
Differential thermal analysis≥998 °C≥998 °C≥1000 °C≥1000 °CN/A≥998 °C
BET surface area≥578 m²/g≥578 m²/g≥620 m²/g≥620 m²/g≥650 m²/g≥580 m²/g
Na2O<1.5%<1.5%<0.5%<0.5%<13.0%<13.0%
RE2O31.5–2.5%1.5–2.5%≥16%≥16%00
Particle size distribution D50<6 µm<6 µm<6 µm<6 µm<6 µm<6 µm
Loss on ignition<13%<13%<13%<13%<15%<15%

* These products will be discontinued after supply lasts. Y-RE16-Pe and Na-Y-Pe are discontinued; their specifications are retained for reference.

Ordering information

ProductFormPackageProduct No.
Y-RE2Powder200 gMSY00022
Y-RE2-PePellet200 gMSY00C22
Y-RE2-PePellet1 kgMSY00C31-1
Y-RE16Powder200 gMSY01022
Na-YPowder200 gMSY03P22

Typical data

SEM image of ACS Material Y-RE2
SEM image of ACS Material Y-RE16
Left: SEM image of ACS Material Y-RE2; Right: SEM image of ACS Material Y-RE16.

Potential applications

  • Applied to make FCC catalyst.
  • Applied to make hydrocracking catalyst.
  • Applied to make high-efficiency adsorbent cleanser and dryer.

FAQ

What is the difference between Y-RE2, Y-RE16 and Na-Y?

They differ in rare-earth content: Y-RE2 has RE2O3 1.5–2.5%, Y-RE16 has RE2O3 ≥16%, and Na-Y has no rare earth (RE2O3 0, Na2O <13.0%). All have a SiO2/Al2O3 molar ratio of 5–6.

What does “-Pe” mean?

Pellet form: 2–3 mm diameter, ~20 mm length.

Do Y-type zeolites need to be calcined before use?

No. This product is calcined and ready to use directly.

Which grades and packages are available?

Y-RE2 200 g (MSY00022); Y-RE2-Pe 200 g (MSY00C22) and 1 kg (MSY00C31-1); Y-RE16 200 g (MSY01022); Na-Y 200 g (MSY03P22).

Where can I find the TDS and SDS?

The Technical Data Sheet (TDS) and Safety Data Sheet (SDS) for this product are available under the price on this page.
