Low Temperature Expandable Graphite

As low as $0.00 $0.00
In stock
SKU# 149

Product Detail

CAS No.: 7782-42-5

Products No.

Expansion

Start

Temperature

(EST‚ °C)

pH Mesh

Packing Density

(mg/cm3)

Expansion Volume

(EV‚ ml/g)

Property

CXG00122

(EG-110-230)

(Discontinued)

110 7.0 80 0.6 230

Super-low Expansion

Start Temperature

EG-150-230

(Discontinued)

150 7.0 80 0.6 230

Please also check our Expandable Graphite.

SKU

Particle Size
(um)

Purity (%)

Expansion Start Temperature

(EST‚ °C)

Expansion Volume

(EV‚ ml/g)

Highlights and Application

CXG22022

80%<75um

≥92%

190℃±10℃

≥20 ml/g

Application: Coatings, Paints, Adhesive, and Textile, which requires finer particle size.

CXG21122

80%<150 um

≥94%

180℃±10℃

≥35 ml/g

Application: Coatings, Paints, Adhesive, and Textile, which requires finer particle size, in case CXG22022 cannot satisfy the flame retardance requirements.

CXG21222

80%<150 um

≥94%

180℃±10℃

≥95 ml/g

Application: Coatings, Paints, Adhesive, and Textile, which requires finer particle size, in case CXG21122 cannot satisfy the flame retardance requirements.

CXG52322

80%>150 um

≥95.0%

180℃±10℃

≥200 ml/g

Application: Spray foams, which require fine particle size.

CXG8B122

80%>180 um

≥95.0%

180℃±10℃

≥230 ml/g

Standard product with fine particle size. Application in PU foam, EPS foam, Sealing Strip, etc.

CXG5B122

80%>300 um

≥95.0%

180℃±10℃

≥250 ml/g

Standard product for all main applications, like PU foam, Coating, Rubber, Adhesive, Construction Materials, etc.

CXG5B022

80%>300 um

≥99.0%

180℃±10℃

≥250 ml/g

Same expansion, but higher purity than CXG5B122

CXG5C022

80%>300 um

≥98.0%

170℃±10℃

≥350 ml/g

High purity, very high free expansion and expansion strength. Application: for all main applications which requires better flame-retardant effects than CXG5B122.



SKU

Mesh

Purity

(%)

Expansion Start Temperature

(EST,°C)

Expansion Volume

(EV, ml/g)

Highlights and Application
*CXGAA222

150

≥92% 175℃ ≥150 ml/g Mainly used in fabric coatings, fire-resistant adhesives and EPS and XPS flame retardants
*CXG00522

80

≥95% 250℃ ≥180 ml/g

With application where extruder used

*CXG00622

50

≥95% 300℃ ≥170 ml/g Highest Expansion Start Temperature

*These three products will be discontinued after sold out.
